Rolling Ball Mill Factory Grinding Machine with Customized Serices Cylinder Liner Rotate Speed 10-50rpm
Product Details:
| Place of Origin: | Hunan，China |
| Brand Name: | TENCAN |
| Certification: | ISO CE |
| Model Number: | QM-50 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | negotiable |
| Packaging Details: | Plywood Case with Foam |
| Delivery Time: | 15-20 days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 280 Set/Sets per Month |
|
Detail Information |
|||
| Weight: | 233kg | Dimension: | 1350*620*1100mm |
|---|---|---|---|
| Rotate Speed: | 10-50rpm | Warranty: | 1 Year |
| Product Name: | Lab Rolling Ball Mill | Feature: | With Sieve Mesh |
| Customized Serices: | Cylinder Liner | Feeding Size (mm): | 0.1 - 10 Mm |
| Key Word: | Rolling Lab Ball Grinding Mill | ||
| Highlight: | 50rpm Rolling Ball Mill,Rolling Ball Mill Factory,Cylinder Liner Rolling Ball Mill |
||
Product Description
Rotate Speed 10-50rpm Rolling Ball Mill with Customized Serices Cylinder Liner
Product Description:
Light roll ball mill, also known as rolling machine altar, is a type of grinding equipment used for ultra-fine grinding and mixing in laboratories and small batch production. Its appealing design, compact structure, user-friendly operation, high efficiency, and uniform granularity make this machine highly regarded in scientific research, educational settings, and production environments. Furthermore, it finds wide applications in industries such as electronic materials, magnetic materials, biological medicine, ceramic glaze, metal powder, nonmetallic minerals, and new materials.
The machine is engineered with an ideal rotation speed, utilizing a rubber roller to power the mill jar into rotation. This motion prompts the balls within the jar to tilt and disperse the materials evenly, thereby yielding optimal grinding results. As a result, the materials are ground into micron-sized powder. The machine also comes equipped with a timing control panel, allowing for pause and cumulative timing functions. This function allows users to customize the working time according to their needs, facilitating time and effort savings while enhancing operational convenience.
Features:
The machine has been designed for stable operation, with high efficiency and low levels of noise and pollution.
Our machine is capable of grinding all types of hard materials using both dry and wet methods, rendering it suitable for both coarse and fine grinding tasks. Additionally, it can be utilized for blending materials.
Safety and Purity
For added safety, our machine is equipped with a protective cover and ensures the finest purity levels while remaining non-polluting.
Durable and Efficient Grinding
The machine is highly resistant to abrasion, ensuring efficient and effective grinding results.
Customizable Options for Different Needs
A wide variety of liner jars, made from materials such as alloyed steel, stainless steel, abrasion-resistant polyurethane, corundum ceramic, and zirconia, are available in volumes ranging from 20L to 2000L, allowing for customization to meet the specific needs of our customers.
Technical Parameters:
| Item | Value |
|---|---|
| Product Name | Lab Rolling Ball Mill |
| Dimension | 1350*620*1100mm |
| Warranty | 1 Year |
| Voltage | 220V-50Hz or 110V-60Hz |
| Feature | With Sieve Mesh |
| Rotate Speed | 10-50rpm |
| Power | 1.1KW |
| Weight | 233kg |
| Key Word | Lab Used Roll Ball Mill, Rolling Ball Mill, Rotating Ball Mill |
| Output (kg/h) | 5-17.5Kg/h |
Applications:
The TENCAN Planetary Ball Mill QM-50 is an advanced grinding apparatus specifically engineered for the fine grinding and mixing of materials in laboratory settings. It is also known as a rotary ball mill, circular ball mill or a planetary ball mill. This machine is commonly used in the fields of nanotechnology, materials science, and metallurgy.
The Rolling Ball Mill is suitable for grinding and mixing various materials, including ores, chemicals, ceramic raw materials, and paints. It is an ideal machine for producing fine and ultrafine powders. The machine is equipped with a high-speed ball mill that can rotate at a speed of 10-50rpm, providing efficient grinding and mixing of materials.
- High efficiency: The TENCAN Planetary Ball Mill QM-50 can grind and mix materials in a short period of time, with an output of 5-17.5kg/h.
- Adjustable feeding size: The machine can handle materials with a feeding size ranging from 0.1mm to 10mm, making it suitable for a wide range of applications.
- Stable performance: The machine has a one-year warranty and is made of high-quality materials, ensuring its durability and stable performance.
- Easy operation: The machine is user-friendly and can be operated by anyone with basic training.
- Compact design: The TENCAN Roll Ball Mill QM-50 is compact in size, making it suitable for use in small laboratories or research facilities.
- Safe and reliable: The machine is designed with safety features, ensuring the safety of the user during operation.
The TENCAN Roll Ball Mill QM-50 finds extensive application across diverse research domains, including nanotechnology, materials science, and metallurgy. It is a staple in laboratories for grinding and blending materials to yield high-quality powders. The accompanying photograph depicts the machine in a laboratory environment, where it is employed to grind and mix various materials for research endeavors.
For more information about the TENCAN Planetary Ball Mill QM-50, please contact us at www.tencanmills.com or call us at +886-731-84939973.
Customization:
Brand Name: TENCAN
Model Number: QM-50
Place of Origin: Hunan, China
Certification: ISO CE
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Plywood Case with Foam
Delivery Time: 15-20 days
Payment Terms: T/T, L/C
Supply Ability: 280 Set/Sets per Month
Voltage: 220V-50Hz or 110V-60Hz
Customized Services: Cylinder Liner
Output (kg/h): 5-17.5Kg/h
Warranty: 1 Year
Dimension: 1350*620*1100mm
Key Words: Rotary Ball Mill, Rolling Ball Mill, Circular Ball Mill
FAQ:
- Q: What is the brand name of this product?
- A: The brand name of this product is TENCAN.
- Q: What is the model number of this product?
- A: The model number of this product is QM-50.
- Q: Where is this product manufactured?
- A: This product originates from Hunan, China, where it is manufactured.
- Q: Is this product certified?
- A: Yes, this product is certified with ISO CE.
- Q: What is the minimum order quantity for this product?
- A: The smallest quantity that can be ordered for this product is 1 set.
- Q: Is the price negotiable for this product?
- A: Yes, the price for this product is negotiable.
- Q: How is this product packaged?
- A: This product is packaged in a plywood case with foam.
- Q: How long is the delivery time for this product?
- A: The delivery time for this product is 15-20 days.
- Q: What are the payment terms for this product?
- A:The acceptable payment methods for this product are T/T (Telegraphic Transfer) and L/C (Letter of Credit).
- Q: How many sets of this product can be supplied per month?
- A: We can supply up to 280 sets of this product per month.
