Output Size ≥300 Mesh Rotating Ball Mill Grinding Machine for Sale with Rotate Speed 10-50rpm
Product Details:
| Place of Origin: | Hunan，China |
| Brand Name: | TENCAN |
| Certification: | ISO CE |
| Model Number: | QM-50 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | negotiable |
| Packaging Details: | Plywood Case with Foam |
| Delivery Time: | 15-20 days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 280 Set/Sets per Month |
|
Detail Information |
|||
| Warranty: | 1 Year | Output Size (mesh): | ≥300 Mesh |
|---|---|---|---|
| Weight: | 233kg | Dimension: | 1350*620*1100mm |
| Customized Serices: | Cylinder Liner | Rotate Speed: | 10-50rpm |
| Key Word: | Ceramic Rolling Ball Mill For Laboratory | Voltage: | 220V-50Hz Or 110V- 60Hz |
| Highlight: | 10-50rpm Rotating Ball Mill,300 Mesh Rotating Ball Mill,Rotating Ball Mill Grinding Machine |
||
Product Description
Output Size ≥300 Mesh Rotating Ball Mill with and Rotate Speed 10-50rpm
Product Description:
The light roll ball mill, alternatively referred to as the rolling machine altar, represents a category of grinding equipment specifically designed for ultra-fine grinding and mixing purposes in laboratory settings and small-scale production environments. Its applications span a diverse range of industries, including electronic materials, magnetic materials, biological medicine, ceramic glazes, metal powders, non-metallic minerals, and emerging materials.
The machine boasts a beautiful design and compact structure, making it a preferred choice for scientific research, teaching, experiments, and production. With its easy operation, high efficiency, and ability to produce uniform granularity, it is considered the preferred equipment for various industries.
To attain optimal grinding outcomes, the machine is engineered with a precisely calculated rotational speed. A rubber roller pulls the mill jar into rotation, prompting the balls within to move in an inclined pattern and effectively disperse the materials. Consequently, this process yields micron-sized powder.
The machine also features a timing control panel, which allows for pausing and cumulative timing. This means that the working time can be set at any point according to the requirements, saving time and labor while also making it easy to operate.
Features:
The machine features stable operation, high efficiency, low noise, and minimal pollution.
It is capable of grinding various hard materials using either a dry or wet method, making it suitable for both rough and fine grinding as well as material mixing.
The machine is equipped with a pouring device and can automatically separate powder and ball media, making it convenient to extract powder.
In addition, it is supplied with a safety cover, providing the highest level of purity and preventing pollution.
This machine also boasts anti-abrasion properties and delivers high grinding efficiency.
Clients have the option to select from a variety of liner jars constructed from diverse materials such as alloyed steel, stainless steel, abrasion-resistant polyurethane, corundum ceramic, and zirconia. Additionally, models with capacities spanning from 20L to 2000L are offered to accommodate diverse requirements.
Technical Parameters:
| Feature | With Sieve Mesh |
|---|---|
| Dimension | 1350*620*1100mm |
| Weight | 233kg |
| Customized Services | Cylinder Liner |
| Power | 1.1KW |
| Product Name | Lab Rolling Ball Mill |
| Key Word | Lab Used Roll Ball Mill |
| Output (kg/h) | 5-17.5Kg/h |
| Rotate Speed | 10-50rpm |
| Output Size (mesh) | ≥300 Mesh |
| Key Features | Rotary Ball Mill, Rotating Ball Mill, Circular Ball Mill |
Applications:
The TENCAN Rolling Ball Mill is a laboratory equipment used for fine grinding of materials. It is also known as a Rolled Ball Mill, Rotating Ball Mill, Rotary Ball Mill, Lab Ball Mill, Grinding Ball Mill, Roller Ball Mill, Laboratory Ball Mill, Planetary Ball Mill, Nano Ball Mill, or Fine Grinding Ball Mill. It is designed and produced by TENCAN, a leading manufacturer of laboratory equipment in Hunan, China. With its high quality and advanced technology, it has obtained ISO CE certification and is widely used in various scientific research institutions, universities, and industrial laboratories.
The TENCAN Rolling Ball Mill is apt for grinding and blending a wide range of materials, including ores, chemicals, paints, ceramic substances, and other particles sized between 0.1mm and 10mm. It finds extensive application in sectors like geological prospecting, metallurgy, electronics, construction materials, ceramics, the chemical industry, pharmaceuticals, environmental protection, and more.
- With Sieve Mesh: The TENCAN Rolling Ball Mill is equipped with a sieve mesh, which allows for easy separation and classification of materials.
- Adjustable Rotating Speed: The rotate speed of the TENCAN Rolling Ball Mill can be adjusted from 10rpm to 50rpm, providing different grinding effects for different materials.
- Lightweight Design: With a weight of only 233kg, the TENCAN Rolling Ball Mill is portable and easy to move, making it suitable for use in various settings.
| Brand Name | TENCAN |
|---|---|
| Model Number | QM-50 |
| Place of Origin | Hunan, China |
| Certification | ISO CE |
| Minimum Order Quantity | 1 set |
| Price | negotiable |
| Packaging Details | Plywood Case with Foam |
| Delivery Time | 15-20 days |
| Payment Terms | T/T, L/C |
| Supply Ability | 280 Set/Sets per Month |
| Weight | 233kg |
| Feeding Size (mm) | 0.1 - 10 mm |
| Key Word | Lab Used Roll Ball Mill |
| Rotate Speed | 10-50rpm |
To order the TENCAN Rolling Ball Mill, please provide the following information:
- Model Number: QM-50
- Quantity: 1 set
- Delivery Address
- Payment Terms
The TENCAN Rolling Ball Mill is a versatile and efficient laboratory equipment designed for fine grinding of various materials. With its advanced technology, lightweight design, and adjustable rotating speed, it is suitable for a wide range of applications in various industries. Contact us today to learn more and place your order!
Customization:
Brand Name: TENCAN
Model Number: QM-50
Place of Origin: Hunan, China
Certification: ISO CE
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Plywood Case with Foam
Delivery Time: 15-20 days
Payment Terms: T/T, L/C
Supply Ability: 280 Set/Sets per Month
Dimension: 1350*620*1100mm
Key Word: Lab Used Roll Ball Mill
Output Size (mesh): ≥ 300 Mesh
Voltage: 220V-50Hz or 110V-60Hz
Power: 1.1KW
TENCAN offers customized services for our Rolling Ball Mill, providing the best solution for your specific needs. Our high-quality Roll Ball Mill is perfect for grinding and mixing materials in the laboratory, with its circular motion ensuring efficient and uniform mixing.
With our customizable options, you can choose the voltage and power specifications that best suit your laboratory's requirements. Our Roll Ball Mill is also designed to provide an output size of at least 300 mesh, ensuring precise and accurate results.
Ordering from TENCAN is hassle-free with our flexible payment terms and quick delivery time. Our Rolling Ball Mill is packaged in a sturdy plywood case with foam for safe transportation and storage. By placing an order of just one set, you can effortlessly acquire our premium-quality product tailored to your laboratory requirements.
Choose TENCAN for your customized Rotating Ball Mill and experience efficient and reliable grinding and mixing in your laboratory.
FAQ:
- Q: What is the brand name of this product?
- A: The brand name of this product is TENCAN.
- Q: What is the model number of this product?
- A: The model number of this product is QM-50.
- Q: Where is this product manufactured?
- A: This product is manufactured in Hunan, China.
- Q: Does this product have any certifications?
- A: Yes, this product is certified with ISO and CE.
- Q: What is the minimum order quantity for this product?
- A: The minimum order quantity for this product is 1 set.
- Q: Is the price of this product negotiable?
- A: Yes, the price of this product is negotiable.
- Q: How is this product packaged?
- A: This product comes packaged in a plywood casing lined with foam for enhanced protection.
- Q: What is the delivery time for this product?
- A: The delivery time for this product is 15-20 days.
- Q: What are the payment terms for this product?
- A: The payment terms for this product are T/T and L/C.
- Q: What is the supply ability for this product?
- A: The supply ability for this product is 280 sets per month.
