220V 0.75KW Rolling Ball Mills Lab Powder Grinding Equipment Mixing Machine

China Tencan 30L 220V-50Hz 0.75KW Wet and Dry Grinding Light Roll Ball Mill For Fine Powder Grinding & Mixing

Overview

The light roll ball mill, also known as the rolling machine altar, is a piece of equipment specifically designed for ultra-fine grinding and mixing in laboratory settings and small-batch production environments. Its elegant design, compact structure, ease of operation, high efficiency, and uniform granularity make it a preferred choice for scientific research, teaching, experimentation, and production. This machine is widely used in industries such as electronic materials, magnetic materials, biomedical fields, ceramic glazes, metal powders, non-metallic minerals, and new materials.

The mill employs an optimal design for its rotational speed, where a rubber roller drags the mill jar into rotation. Inside the jar, balls create an inclined flow movement that effectively disperses the materials, achieving optimal grinding results. Consequently, the materials are refined into micron-sized powder.

Additionally, the machine is equipped with a timing control panel that offers pausing and cumulative timing functions. Users can set the working time according to their specific needs at any time, making it a time-saving and labor-efficient option that is also straightforward to operate.

Working Principle

During the milling process, the grinding media and materials inside the tank are rotated to a specific height. Subsequently, due to gravity, they descend along the tube wall. The materials undergo crushing through the impact force exerted by the grinding media, as well as the friction and shearing actions resulting from the rolling and sliding movements of the grinding media.

Applications

The light roll ball mill finds extensive application across various industries, including those related to electronic materials, magnetic materials, biomedical products, ceramic glazes, metal powders, non-metallic minerals, and emerging materials, among others.

Features

1. Stable running, high efficiency, low noise and non-pollution
2. Both dry and wet grinding methods can be employed to process all varieties of hard materials; the machine is adept at performing both coarse and fine grinding tasks, and it is also suitable for mixing materials.
3. The machine is self-equipped with pouring device, and has function of separating powder and ball media automatically, convenient to output powder.
4. Equipped with safety cover, finest pure degree and non-pollution.
5. Anti-abrasion, high efficiency of grinding.
6. A variety of liner jars in different materials can be selected such as alloyed steel, stainless steel, abrasion-resisting polyurethane, corundum ceramic, zirconia, and etc. Models of 20-2000L volume are available for customers’ needs.

Selection Helps of Light Roll Ball Mill

1. Model Instruction: QM-(VOLUME)-(A: means speed is adjustable, B: common model). Example: QM-50-A means it is a model of 50L volume roll mill with function of speed adjusting;
2. Model No of roll mill can be selected according to quantity (weight) of grinding materials;
3.The selection of materials for jars and balls can be based on the properties of the material being processed.
4. Automatic pouring device and anti-dust cover is available for your option.
5. Switching pots is effortless, and the machine is adaptable for both wet and dry grinding processes.

Technical Parameters

Accessories of Light Roll Ball Mill

In addition to the light roll ball mill machine, our factory offers a diverse range of roll mill pots, including stainless steel mill pots, zirconia mill pots, alumina mill pots, nylon mill pots, PU mill pots, tungsten mill pots, and traditional ceramic mill pots, among others.

We can also provide all kinds of mill balls like stainless steel balls, zirconia balls, alumina balls, tungsten carbide balls, agate balls, hard metal balls, silicon nitride balls, high wear resistant steel ball, manganese steel balls, and other special metal materials.
