Stainless Steel PMMA Vacuum Glove Box for Laboratory 600*500*500mm Chamber Size
Product Details:
| Place of Origin: | Hunan, China |
| Brand Name: | TENCAN |
| Certification: | CE ISO |
| Model Number: | GBV-1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | One Piece |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood case with foam |
| Delivery Time: | 25-35 working days after getting full payment |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 500 pcs per month |
|
Detail Information |
|||
| Product Name: | Stainless Steel Vacuum Glove Box | Model No.: | GBV-1 |
|---|---|---|---|
| Material: | Stainless Steel & PMMA Material | Chamber Szie: | 600*500*500mm |
| Packing: | Plywood Case | Place Of Origin: | Hunan, China |
| Pressure Holding Time: | More Than 12 Hours | Certificate: | CE ISO |
| Highlight: | 600*500*500mm Chamber Size Vacuum Glove Box,Laboratory PMMA Vacuum Glove Box,Stainless Steel Vacuum Glove Box |
||
Product Description
China Tencan Stainless Steel Vacuum Laboratory Glove Box Chemistry Glove Box With Corrosion resistance & Good Sealing Performance
Overview
Certain materials are highly sensitive to water and oxygen during chemical experiments, making research challenging to complete. While vacuum vessels can meet the requirements for anaerobiosis and vacuum levels, they lack convenience in operational procedures. Vacuum glove boxes, however, address both the environmental and operational challenges.
The stainless steel vacuum glove box is a laboratory equipment which can be filled with high purity inert gas into the box to filter out the active substances circularly. It is also called glove box, operation box, inert gas protection box, and dry box.
Working Principle
During chemical experiments, certain materials are extremely sensitive to water and oxygen, posing significant obstacles to research completion. Although vacuum vessels are capable of achieving the necessary anaerobic conditions and vacuum levels, they fall short in terms of operational convenience. Conversely, vacuum glove boxes offer solutions to both environmental sensitivity and operational complexities.
Features
1.Constructed entirely of stainless steel, reinforced with plastic, and finished with a protective spray, the entire box possesses robust strength, corrosion resistance, and ease of cleaning.
2.The front side of the operating box is made of tempering glass, it has wide angle without dead corner.
3.The interior lighting and the porous socket can be locally heated by the electric stove.
4.The gloves are made of thick latex gloves,well-sealed and durable.
5.The sealing device boasts a novel design, offers reliable sealing, and is convenient to open.
6.Inside and outside of the box are equipped with water faucet for input of water and gas;
7.The two doors of the transition chamber eliminate the need for repeated vacuum extraction processes in the main box.
Technical Parameters
| Parameters of TENCAN Stainless Steel Vacuum Glove Box | |||||||
| No. | Model No. | Total Dimensions | Box Size | Transition Cabin Size (Optional) |
Left Door Size (Optional) |
Glove Port Size | Vacuum Degree |
| 1 | GBV-1 | 1030*570*530mm | 600*500*500mm | Φ200*280mm | 255*330mm | Φ150mm | -0.1~0.0Mpa Keep vacuum for more than 12 hours |
| 2 | GBV-2 | 1295*715*675mm | 800*650*650mm | Φ273*350mm | 360*480mm | Φ150mm | |
| 3 | GBV-3 | 1755*776*1010mm | 1200*700*950mm | Φ350*400mm | 450*600mm | Φ196mm | |
